Selecting an Address
Each keypad must be assigned a different address using the DIL switches located
on the left hand side of the PCB. The table below shows the keypad addressing:
Address DIL 1 DIL 2 DIL 3 DIL 4
1 On/Off Off Off Off
2 Off On Off Off
3 Off Off On Off
4 Off Off Off On
5 On Off Off On
6 Off On Off On
7 Off Off On On
8 On Off On On
Engineers On On On On
!
"
Never set two keypads on the same network to the same address.
Keypads are factory set to address 1.
