LCD & LCD-Pro Installation Manual Installation
INS180 13
Other Features
Programmable ‘Info.’ LED
The ‘Info.’ LED on the front of the keypad can be programmed to mimic the keypad
output or show the armed status of an area. For details on programming the ‘Info.’
LED, please refer to the Premier 888/8168 Installation Manual.
Adjustable Backlighting
To adjust the keypad backlighting press the YES key for 5 seconds, then with the
YES key still pressed use the SCROLL key to increase or decrease the
backlighting until the required brightness is achieved, then release both keys.
!
"
The backlight can only be adjusted when the keypad is not in a menu.
Testing the Keypad
Whenever new devices are connected to the networks, they must be confirmed
onto the system using the ‘Check Networks’ menu option. For details on confirming
devices, please refer to the Premier 888/8168 Installation Manual.
Testing the zones
The zones on the keypad can be individually tested to ensure correct operation,
this can be done by either using the ‘Walk Test’ menu option or the ‘View Zone
Status’ menu option. For details on walk testing or viewing zones, please refer to
the Premier 888/8168 Installation Manual.
Testing the Output
The output on the keypad can be tested to ensure correct operation, this can be
done using the ‘Output Test’ menu option. For details on testing outputs, please
refer to the Premier 888/8168 Installation Manual.
Testing the Speaker (Premier LCDL only)
The speaker output on the keypad can be tested to ensure correct operation, this
can be done using the ‘Output Test’ menu option. For details on testing outputs,
please refer to the Premier 888/8168 Installation Manual.
The speaker volume for the keypad is also fully adjustable. For details on adjusting
the speaker volume please refer to the Premier 888/8168 Installation Manual.
