No. Items Range Default Description
P79
The stop angle of thread
clamping
5-359 270
P80 Trimming engage angle
0-359 5
P83 Stopping strength after trimming
10-100 20
P86
Up and down needle position
distance
15-345 170
Up and down positioning distance angle (1 degree for every 4 values)
P87 Wiping thread return delay time
10-990 50
Make sure the wiper returns to its original position
P88 Stopover distance
10-100 30
P89 AC overvoltage setting
500-1023 880
P92
Correct the electrical angle of
motor
160
Reading the initial Angle of encoder, the factory default was set, please do
not change the values (parameter value cannot be changed manually,
random change it will result the control box and motor abnormal or
damaged).
P93
The starting time of the half
back pedaling function (ms)
10-900 100
P99
Starting tight seam stitch length
0-5.0 0.5
P100
Direction of starting tight seam
0-1 0
P101
The Start angle of thread
slacking
1-359 30
Song line start angle (defined as 0°under calculation)
P102
The stop angle of thread
slacking
1-359 180
Loose wire end angle (defined as 0°under calculation, must be greater than
P101 parameter value)
P103 Thread slacking strength
1-5 3
P105
Pattern freedom sewing mode
selection
0-8 0
0: OFF
1-8: Pattern freedom sewing mode
P107 Starting tight seam speed
100-1200 500
P108
Starting tight seam stitch
number
0-12 1
P109
The delay time before thread
wiping
5-990 5
Interval time before entering thread wiping action after finding the upper
positioning
P110
Trimming back time (ms)
60-990 65
Make sure the thread trimming device returns to its original position
P111
Clamp function without any
thrum switch
0-1 0
P112
The delay time before hook
thread with clamp function
without any thrum
0-990 100
P113
The hook thread action time
with clamp function without any
thrum
0-990 30
P114
The return back time of hook
thread with clamp function
without any thrum
0-990 30
