No. Items Range Default Description
P177
1mm forward stitch length
reference value setting
0-200
27
P178
1mm backward stitch length
reference value setting
0-200
28
P179
2mm forward stitch length
reference value setting
0-200
55
P180
2mm backward stitch length
reference value setting
0-200
56
P181
3mm forward stitch length
reference value setting
0-200
75
P182
3mm backward stitch length
reference value setting
0-200
76
P183
4mm forward stitch length
reference value setting
0-200
100
P184
4mm backward stitch length
reference value setting
0-200
99
P185
5mm forward stitch length
reference value setting
0-200
123
P186
5mm backward stitch length
reference value setting
0-200
120
Note: the initial value of parameters is for reference only, and the actual value of parameters is subject to the real object.
3 Error Code List
Error Code Problem Measure
E01
Over-voltage
Turn off the system power and check whether the power supply voltage is
correct. (Or whether it exceeds the specified rated voltage).
E02
Low-voltage
Turn off the system power and check whether the power supply voltage is
correct. (
Or whether it is lower than the specified rated voltage).
E03
Abnormal communication between
the main CPU and the driver CPU
Turn off the power and check whether the connector is connected to the
operation panel and the cable condition.
E05
Speed control unit connection is
abnormal
Please turn off the power and check whether the connector is connected to the
speed controller and the cable condition.
E07
Main shaft motor rotating abnormally
Please rotate handwheel to check if the spindle motor is locked. Check if the
encoder cable of the motor and the power cable of the motor are connected to the
connector. Check if the power supply voltage is normal and whether the sewing
speed is too high.
E10 Solenoid over-current protection
Turn off the system power supply, please check the solenoid (solenoid valve)
connector or solenoid (solenoid valve) is broken or not.
