editing interface "01 1 3.0", press the 1st or 2nd column , to adjust the number of 00-99 stitches, press
the 4th column
, to adjust Repeat 1-9 times, press to adjust the stitch length. After the
setting is completed, press the S key to confirm. Short press P key to exit to the main interface.
1.2.6 Pattern Constant-stitch Sewing Editing
In the multi-section sewing mode, long-press pattern constant-stitch sewing key on the main interface to
switch to pattern constant-stitch sewing editing interface "d-01 3.0", press the fourth column
, to
adjust the d01-d15 segment number, and press
to adjust the current segment Stitch length. Short press
P key to exit to the main interface.
2 User Parameter
No. Items Range Default Description
P01 Maximum sewing speed (rpm) 100-3700
3700
Maximum speed of machine sewing
P02 Set accelerated curve (%) 10-100
80 Set the acceleration slope
P03 Needle UP/ DOWN UP/DN
DN
UP: Needle stops at Up position
DN: Needle stops at Down position
P04 Start back-tacking speed (rpm) 200-3200
2000
P05 End back-tacking speed (rpm ) 200-3200
2000
P06 Bar-tacking speed (rpm) 200-3200
2000
P07 Soft start speed (rpm ) 200-1500
1500
P08 Stitch numbers for soft start 1-15
2
P09
Automatic constant-stitch
sewing speed (rpm)
200-4000
3700 Speed adjustment for automatic constant-stitch sewing
P10
Automatic end back-tacking
sewing
ON/OFF
ON
ON: After last seam of constant stitch sewing, it will automatic execute the
End Back-Tacking sewing function. When turn on, the Stitch-Correction is
invalid.
OFF: Automatic End Back-Tacking will not execute after last seam, but
can be done by pedal manually.
P12
Start back-tacking running mode
selection
0-1 1
0: Could be arbitrarily stop and start
1: Automatically perform actions
P13
Ending mode of start
back-tacking
CON/STP CON
CON：Start Back-Tacking is completed automatically continued for next
action.
STP：After the number of stitches is completed, stop automatically.
P14
Slow start function selection
ON/OFF
OFF
P15
Manual Switch A
0-6
5
0: OFF
1: half stitch
2: one stitch
3: continuous half stitch
4: continuous one stitch
5: Back-tacking when machine stop or pause
6: Tight seam function
P16
Back-tacking speed limit
0-3200
3000
The function is disabled when the value is less than 100.
P17-N04
Voice language selection
0-1
1
0: Off, 1: C
hinese, 2: English, 3: Vietnamese , 4: Portuguese, 5: Turkish, 6:
Spanish, 7: Russian , 8: Arabic
0: OFF, 1: ON
P20
End back-tacking running mode
selection
0-1 1
1: Manual, pedal controlled, can be stopped and started arbitrarily
P17-N05 Voice finction
0-1
0
2: Automatic, touch the pedal to automatically execute back-tacking
