TEXI Compacta
User manual for the portable blind stitch machine model Compacta
Contents
1. General safety rules
2. Construction of the machine
3. Set the machine at work place
A. Location
B. Installation of the thread rack
C. Connecting the foot pedal
D. Installation of the knee lifter
4. Lubrication
5. Needles and threads
6. Needle exchange
7. Sewing machine
8. Inserting the material and start of sewing
9. Thread tension adjustment
10. Stitch length adjustment
11. Needle penetration depth adjustment
12. Removing material from the machine
13. Skip stitch apparatus
Portable blind stitch machine TEXI model Compacta
is a sewing machine designed for woven and knitted fabrics. Machine should not be used for purposes other than those to
which it was intended.
Failure to follow the above rule may be dangerous and may cause permanent damage to the machine.
MODEL: Compacta
Voltage 230V 50/60Hz
Noise level: 41dB(A)
Vibration 0,2 m/sec2
Sewing speed 1200 stitches./min.
Net weight 11 kg
Measurements in the box550 x 250 x 650 mm
IMPORTANT!
This manual contains important instructions on how to safely, effectively and economically use the machine. Adherence to its
instructions will help avoid danger, reduce stoppage time, improve reliability and durability of the machine. The manual must
always be available at the workplace.
Supplier shall not be liable for damages resulting from improper use or misuse of the service.
ATTENTION:
All works related to electrical installation must be performed by qualified electrician.
Follow the current electrical and safety standards.
