USER’S MANUAL
The overlock machines TEXI, model Tre 04 T, Quattro 24 T and Cinque 35 T, are high speed
sewing machines, designed for sewing and serging woven or knitted materials or other textiles.
Attention!
The machine is not to be used for other materials than those for which it has been designed.
Non-observance of this rule places the user at risk and can cause irreversible damage to the machine.
Before use, the user should become acquainted with this instruction manual, general safety precautions and maintenance
instructions.
1. Before starting work
1. After turning-on the machine and during its operation, do not touch the needle or other moving parts of the
machine.
2. During sewing, do not put fingers into the needle guard.
3. Before uninstalling guards, turn power off.
4. Turn machine off before leaving it unattended.
5. Do not allow hair, loose clothing, fingers or any objects to be in the vicinity of the pulley during machine run.
6. Do not clean the machine with paint thinner.
Technical Specification
Model Tre 04 T Quattro 24 T Cinque 35 T
Application Light & medium
materials
Light & medium
materials
Light & medium
materials
Power supply 230 V 230 V 230 V
Frequency 50 ~ 60 Hz 50 ~ 60 Hz 50 ~ 60
Number of
Needles
1 2 2
Number of threads 3 4 5
Vibrations 100 um 100 um 100 um
Sewing speed
(max)
7000 stitches per
minute
6500 stitches per
minute
6500 stitches per
minute
Stitch Width 4 mm 6 mm 8 mm
Needle B-27 with
appropriate tips to
the type of sewn
materials
B-27 with
appropriate tips to
the type of sewn
materials
B-27 with
appropriate tips to
the type of sewn
materials
Lubricating oil Oil for high speed
machines
Oil for high speed
machines
Oil for high speed
machines
Nett weight 30 kgs 30 kgs 30 kgs
Packing dimension 502 × 410 × 526
mm
502 × 410 × 526
mm
502 × 410 × 526
mm
3
TEXI Tre 04 T, Quattro 24 T, Cinque 35 T Operation Manual
