18
Gear
Drive
Midsize
ADJUSTMENTS
DRIVE BELT TENSION ADJUSTMENT
Drive belt tension can be adjusted to one of three
settings to account for various mowing conditions.
1. Adjust by moving the spring anchor bolt to
position 1, 2 or 3.
• Position 1 will provide the least amount of hand
effort and wheel traction.
• Position 3 will provide the highest amount of hand
effort and wheel traction.
TIRE PRESSURE ADJUSTMENT
Tire pressures should be maintained at
14 psi (1.0 kg/cm
2
).
NOTE: Adjusting tire pressure slightly can improve
tracking. Increase pressure on the side the machine
tracks toward and decrease it on the other side.
