10
Gear
Drive
Midsize
LUBRICATION
MACHINE LUBRICATION
Every 50 Working Hours - Lubricate the following points with grease:
1) Caster wheel pivots (2 points)
2) Caster wheel bearings on wheel hub (2 points)
3) Drive Wheel Bellcranks (2 points)
4) Brake Levers (2 points)
5) Idler pivot bearings:
a) Engine to cutterdeck belt tensioner
b) Cutterdeck belt tensioner
c) Transmission drive belt tensioner
6) Shaft Couplers (2 points)
