37
Gear
Drive
Midsize
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
FIGURE 8
PEERLESS TRANSMISSION
2721693-08
SEE YOUR PEERLESS DEALER FOR
REPLACEMENT PARTS.
2308136 PEERLESS TRANS MODEL 700-078
(COMPLETE UNIT AVAILABLE THRU TEXTRON)
(INDIVIDUAL COMPONENTS AVAILABLE
THROUGH PEERLESS 1-800-558-5402)
8-1 772099A COVER,TRANSMISSION 1
8-2 780086A BEARING,NEEDLE 1
8-2A 780142 BEARING,NEEDLE 1
8-3 770090A CASE,TRANSMISSION 1
8-4 776134 COUNTERSHAFT 1
8-8 792089A SHIFT KEY 4
8-9 784266 COLLAR,SHIFT 1
8-10 784376 ROD & FORK ASSY,SHIFT 1
8-11 778154 GEAR,BEVEL (42 TEETH) 1
8-12 778176 PINION,BEVEL (14 TH ST) 1
8-20 792077A BALL,STEEL,5/16" 1
8-21 792078 SET SCREW,3/8-16 X 3/8 1
8-22 792079 SPRING 1
8-24 780071 BEARING,THRUST 1
8-25 792073A SCREW,1/4-20 X 1-1/4 6
8-27 792035 RING,RETAINING 1
8-28 788040 RING,RETAINING 1
8-29 780072 WASHER 6
8-30 780108 WASHER 5
8-31 780065 WASHER 2
8-32 792001 “O” RING 2
8-34 780105A BUSHING,FLANGED 2
8-45 * 2308007 NEUTRAL SWITCH NC 1
8-49 778146A GEAR,SPUR (37 TEETH) 1
8-50 778125 GEAR,SPUR (35 TEETH) 1
8-51 778239A GEAR,SPUR (32 TH ST) 1
8-52 778124A GEAR,SPUR (30 TEETH) 1
8-53 778250 GEAR,SPUR (27 TEETH) 1
8-56 778145 GEAR,SPUR (12 TH ST) 1
8-57 778151 GEAR,SPUR (15 TEETH) 1
8-58 778240 GEAR,SPUR (18 TH ST) 1
8-59 778126A GEAR,SPUR (20 TEETH) 1
8-60 778249 GEAR,SPUR (23 TEETH) 1
8-65 780139 WASHER,THRUST 1
8-66 776135 SHAFT,INPUT (3-11/16") 1
8-67 776421 SHIFTER & BRAKE SHAFT 1
8-71 788069 SEAL,SQUARE CUT 1
8-72 792074 THREADED PLUG 1
8-81 786081 CHAIN,ROLLER #41 1
8-82 786082 SPROCKET (9 TEETH) 1
8-83 786083 SPROCKET (18 TEETH) 1
8-89 780092 BALL BEARING 2
8-90 788067B GREASE (32 OZ BENTONITE)
8-150 510334 GASKET ELIMINATOR
(LOCKTITE #515)
* (NOT ILLUSTRATED)
