ITEM PART NO. DESCRIPTION QTY

BZT 2000

Series

11-1 2721375 HARNESS-WIRING 1

11-2 148082-20 FUSE-20 AMP 2

11-3 108061-13 CABLE-BATTERY 1

11-4 158135-01 SWITCH-SEAT NO 1

11-5 158136 WIRE-SEAT SWITCH 1

11-6 48030N HOUR METER ASSY 1

11-7 2722227-02CABLE-BATT W/CONDUIT 1

(INCLUDES ITEMS 21 & 22)

11-8 128010 KEY-SWITCH 1

11-9 2722325 RELAY 3

11-10 2188154 MODULE-DELAY 1

11-11 2188153 SWITCH-CLUTCH 1

11-12 2721337 CLUTCH-ELECTRIC 1

(USE ON ALL MODELS EXCEPT 19HP)

(INCLUDES 2720949 WIRE ASSY)

2722016 CLUTCH-ELECTRIC 19HP 1

(USE ON 19HP MODELS ONLY)

(INCLUDES 2720949 WIRE ASSY)

11-13 2188172 HARNESS-JUMPER 2

11-14 108208 SWITCH-DBL POLE 2

11-15 2188156 SWITCH-NONO DBL POLE 1

11-16 38665 SOLENOID 1

11-17 2188224 HARNESS-JUMPER 1

11-18 108061-04 CABLE-SOL/STARTER 1

11-19 2188225 WIRE-GROUND 1

11-20 2721903 HARNESS-CONTROL PNL 1

11-21 112386 BOOT, BAT. TERM POS 1

11-22 2308095 COVER-TERMINAL 3

11-23 2721814 SWITCH-DECK HEIGHT 1

11-24 2721815 SWITCH-LIGHT 1

FIGURE 11

KAWASAKI WIRE HARNESS

2722089-11
