59
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
BZT 2000
Series
FIGURE 17
STEERING/INSTRUMENTS
2722089-17
17-1 2720997 S ENGINE DECK W/LABS 1
17-2 48030N HOUR METER ASSY 1
17-3 2188161 VALVE-TANK SELECTOR 1
17-4 108009-04 CONTROL-CHOKE 40.0 1
(USE WITH KOHLER ENGINES)
108009-03 CONTROL-CHOKE 51.0 1
(USE WITH KAWASAKI & LIQUID COOLED
ENGINES ONLY)
17-5 2182344.7 LEVER-CONTROL 2
17-6 2182434.7 BRKT-TRACTION LEVER 2
17-7 2183074 BRACKET-HANDLE 2
17-8 2188144 GRIP-.75 IDX12 2
17-9 2188145 BEARING-SELF ALIGNED 4
17-10 64123-15 BLT-HEX 3/8-16X3/4 8
17-11 64141-4 NUT-WLF 3/8-16 8
17-12 4112105.7 WLDMT-MTN CNTRL RH 1
* 4112104.7 WLDMT-MTN CNTRL LH 1
17-13 64205-011 BLT-MET M10-1.5X40 2
17-14 A110406 BLT-MET M10-1.5X30 16
17-15 64237-03 LOCKNUT-NYLON M10-1.5 16
17-16 800488 LOCKWASHER-M10 4
17-17 64025-04 NUT-HEX 3/8-24 1
17-18 2722723.5 WLDMT-CRADLE 1
17-19 2183073 SPACER 2
17-20 A1104057 BOLT-M10-1.50X25 2
17-21 64152-23 1/4-20X3/8 LG SP SCREW 2
17-22 2222092 PLATE-CHOKE MOUNT 1
* NOT ILLUSTRATED
