ITEM PART NO. DESCRIPTION QTY

BZT 2000

Series

FIGURE 15

SEAT ASSEMBLY & ROPS

2187026

15-1 2720975 SEAT-SUSPENSION 1

(INCLUDES ITEMS 2-10)

2720975-01SEAT CUSHION 1

2720975-02BACK CUSHION 1

2720975-05CABLE ASSEMBLY 2

(INTERNAL SEAT COMPONENT NOT

ILLUSTRATED)

2720975-08ASSY-SEAT BACK PANEL 1

15-2 2721093 RH ARM REST 1

15-3 2721094 LH ARM REST 1

15-4 158135-01 SWITCH, SEAT NO 1

15-5 64123-69 BLT-HEX 5/16-18X1-1/2 2

15-6 64123-49 BLT-HEX 1/4-20X1/2 2

15-7 2720975-04SLIDE RAIL-ADJ 1

15-8 2720975-03SLIDE RAIL-SLAVE 1

15-9 2720975-06SPACER-NYLON 5/8" 2

15-10 2720975-07SPACER-NYLON 3/8" 4

15-11 158136 WIRE-SEAT SWITCH 1

15-12 2722427.7 PLATE-SEAT 1

15-13 64141-6 NUT-WLF 5/16-18 4

15-14 2198096 SCREW-CAP WSHR HD 4

15-15 64188-39 PIN-CLEVIS3/8X1-3/8W/OHL 2

15-16 64175-04 PUSHNUT 3/8 DIA 2

15-17 38371-01 BRG-NYLINER 3/8 2

15-18 48228A CABLE CLIP-INSULATED 1

15-19 64152-23 SCREW 1/4-20X3/8 1

15-20 64139-16 BLT-WLF 5/16-18 X 3/4 6

OPTIONAL ROPS:

15-21 970162 ATT-ROPS

(INCLUDES ITEM 22)

15-22 *2208260 S-SEAT BELT 1

* NOT ILLUSTRATED
