SECTION 2 CESSNA
OPERATING LIMITATIONS MODEL 172S NAV III
GFC 700 AFCS
U.S.
FAA APPROVED
AIRSPEED LIMITATIONS
Airspeed limitations and their operational significance are shown in
Figure 2-1. Maneuvering speeds shown apply to normal category
operations. The utility category maneuvering speed is 98 KIAS at 2200
pounds.
AIRSPEED LIMITATIONS
SYMBOL SPEED KCAS KIAS REMARKS
V
NE
Never Exceed Speed 160 163 Do not exceed this speed
in any operation.
V
NO
Maximum Structural
Cruising Speed
126 129 Do not exceed this speed
except in smooth air, and
then only with caution.
V
A
Maneuvering Speed:
2550 Pounds
2200 Pounds
1900 Pounds
102
95
88
105
98
90
Do not make full or abrupt
control movements above
this speed.
V
FE
Maximum Flap
Extended Speed:
FLAPS 10°
FLAPS 10° to FULL
107
85
110
85
Do not exceed this speed
with flaps down.
-----
Maximum Window
Open Speed
160 163 Do not exceed this speed
with windows open.
Figure 2-1
172SPHBUS-00
2-4
