McCAULEYPROPELLERSYSTEMS
CONSTANTSPEEDCOMPOSITEOWNER/OPERATOR
INFORMATIONMANUAL
(4)Rotatethepropellerslowlybyhandandmakesurethedistancebetweentheslingerringandthe
feedertubeisinalignmenttolerance.Adjustthefeednozzleasnecessarytogettherequired
alignment.
9.PropellerAnti-IceFluidTubesRemovalandInstallation
A.TubeRemoval(RefertoFigure202,Figure1001).
NOTE:Itemnumbersinparenthesis(XXX)refertoitemsidentiedinFigure1001unless
specicallynotedotherwise.
(1)Removethepropellerspinner,refertothePropellerRemoval/Installationsectionofthismanual
forinstructionstoremovethepropellerspinner.
(2)Loosentheclamps(241)attachingtheTKSsprayheadtube(partofthelletassembly)andthe
slingerringassembly.
(3)Removethehose.
B.TubeInstallation
(1)Positionthehoseonthesprayheadassemblyandtheslingerringassembly.
(a)Makesurethehoseisnottwistedorkinkedasitisroutedaroundthepropellerassembly.
(2)Securehosewithclamps(241).
(a)Makesuretheclamps(241)arepositionedtowardsthepropellerhubinamannerthatwill
notinterferewiththepropellerblade,spinner,orslingerringassembly.
(b)Afterclamps(241)havebeentightenedandthehose(242)issecure,cutoffandremove
excessstrapmaterialfromtheclamps.
(3)Doanalcheckofhoseroutingtomakesurethehoseisnottwistedorkinkedasitisrouted
aroundthepropellerbladeandthatthereissufcientlengthtothehosetoallowforthepropeller
bladetotravelwithoutdamagingthehoseorthepropellerassembly.
(4)Installthepropellerspinner,refertothePropellerRemoval/Installationsectionofthismanualfor
instructionstoinstallthepropellerspinner.
10.BulkheadAssemblyandPropellerSlingerRingAssemblyRemovalandInstallation
NOTE:Itemnumbersinparenthesis(XXX)refertoitemsidentiedintheAnti-IceSystemIllustrated
PartsListFigure1001unlessspecicallynotedotherwise.
A.ForpartnumberP34017898-0381propellerswithE-8102spinnerassemblies(CessnaT240)
installations:
(1)Removal.
NOTE:TheslingerringforCessnaT240installationisanintegralpartofthespinnerbulkhead
assembly(203).
(a)Removethepropellerandspinnerfromtheengine,refertothePropellerRemoval/
Installationsectionofthismanualforinstructionstoremovethepropellerandpropeller
spinner.
NOTE:Spinnerbulkheadwillstaywiththepropellerasitisbeingremovedfromthe
engine.
(b)Makesurethereisanalignmentmarkonthespinnerbulkhead(203)totheNo.1propeller
blade.Ifthealignmentmarkhasbeenremoved,useafelttippinandmakeanewalignment
mark.
(c)Removeandretainbolts(220)andwashers(221)securingthespinnerbulkheadassembly
(203)tothebulkheadmountingplateassembly(219).
(d)Removethespinnerbulkheadassembly(203).
(2)Installation
(a)Alignthespinnerbulkhead(203)totheapplicablepropellerbladealignmentmarks.
61-13-45Page209
©McCauleyPropellerSystemsJan9/2017
