9
Position Less than 10 minutes
continuous operation
Continuous
operation
Front up 30° 25°
Front down 30° 25°
Left or right
side down
30° 25°
OPERATION section 4.4
MAXIMUM ENGINE INCLINATION RECOMMENDATIONS
When using an engine in an inclined position continuously, the following points must be
remembered:
• 1. On water cooled engines there is a possibility of an air pocket forming in the cylinder head due to
inadequate circulation and/or coolant vaporization.
• 2. The effective volume of the fuel tank becomes less, so air suction must be prevented.
CAUTION!
Continuous operation on slopes exceeding
25° is not recommended.
