TGB BF8 - Carburetor Idle Speed; Throttle Valve

38
2-10 CARBURETOR IDLE SPEED
Note:
Please place main stand to park the motorcycle
for inspection.
Start engine and adjust idle speed at warm
engine condition.
* Adjust Procedure *
Connect engine speed meter.◎
Adjust idle speed to adequate range ◎
with cross screw driver.
Note:
(1) Increase engine speed by rotating the screw clockwise.
(2) Reduce engine speed by rotating the screw counter-clockwise.
(3) Engine idle speed range:
1800±100 rpm.
2-11 THROTTLE VALVE
Inspection: Check if the throttle valve
operation is smooth.
Note:
(1) Throttle lever free play: 2 ~ 6 cm.
(2) Micro-adjustment is performed at throttle
lever. Macro-adjustment is performed at
carburetor throttle valve cable.
A. Throttle Lever Gap Adjust
Procedures:
Open dust boot.◎
Loose lock bolt.◎
Adjust by rotating adjust nut.◎
Note:
1. Increase engine speed by rotating nut
clockwise.
2. Reduce engine speed by rotating nut
counter-clockwise.
Tighten adjust nut after adjustment.◎
Close dust boot.◎
