3 Appendix
3.1 4G Modem Card Adapter Board
3.1.1 Package Content
The 4G Modem Card Adapter Board (Figure 3 A) will
be delivered together with
• 1 USB 3.0 cable (Figure 3 B)
• 1 USB cable with USB-C connector (Figure 3 C)
• 4 MHF4 type antenna cables (Figure 3 D)
• 4 UMTS/LTE/NR antennas (Figure 3 E)
• 1 Thermal Pad (Figure 3 F)
• 1 Screw to fix M.2 Card (Figure 3 G)
• 4 MHF4 to SMA antenna cables including washers
and nuts (Figure 3 H)
GNSS Antenna and Power supply are not part of the
4G Modem Card Adapter Board delivery.
Ordering Number: L30960-N6951-A100
Figure 3: 4G Modem Card Adapter Board Kit
