See "Connecting to the Appliance"on page20 to continue the installation process.
Using the Optional Sliding Rail System
The optional sliding rail system allows for the appliance to be extended out in front of the equipment rack,
possibly easing access to other racked appliances. This is rarely necessary.
The sliding rail mounts fit into any standard 19" equipment rack.
Ensure you have all the necessary components before proceeding. In addition to the supplied components,
you will need a #2 Philips screwdriver.
To mount the appliance
1. Install the two front ear mounting brackets on the appliance using the included screws and a #2 Phillips
screwdriver.
2. Fit the front end of each mount into either side of the rack and pull the spring-loaded latch at the rear to snap
it in place.
KeySecure k570 Appliance : Installation Guide
16 June 2020,Copyright© 2020 Thales Group.All rights reserved.
16
