Qty Item
1
Friction Rail Mounting Bracket Set
See "Using the Supplied Mounting Brackets"on page13 for installation instructions. Set includes:
>
(2) side rails
>
(8) side rail screws
>
(2) sliding rear brackets (fit into the rails for rear support adjustable positioning)
CAUTION! The included mounting hardware is meant for static positioning of the
appliance. The long tab that slides into the bracket, applied to each side of the appliance, is
adjustable for fitting the appliance into racks of varying depth - it must not be used to extend
the appliance out of the rack.
Optional gliding rails with rolling bearings are available for situations where rolling excursion
of the appliance, while attached to the rack, is required for maintenance. See "Optional
Items"on page11.
1
Friction Rail Rack Mounting Screws/Cage Nuts
Set includes:
>
(8) M5 cage nuts
>
(8) M5x14 rack screws
If you did not receive this set, you can request one from Thales Group (part number: 216-000035-001) or obtain
your own suitable screws/nuts.
KeySecure k570 Appliance : Installation Guide
16 June 2020,Copyright© 2020 Thales Group.All rights reserved.
7
