Tharo Systems V-425E - Installing Label Dispenser

5 Accessories
5.2 Installing the Label Dispenser
Please complete the preparation steps on page 28 before installing the Label Dispenser.
29
SCREWS
CONNECTION CABLE
SENSOR
PAPER FEED
ROLLER
LABEL DISPENSER MODULE
= Recommended label liner
thickness: 0.006 mm ± 10% and a weight of 65 g/m
2
± 6%
=
The maximum width when using the Label Dispenser is 110 mm.
= Set the Stop Position to 9mm when using the Label Dispenser
.
NOTICE
