Tharo Systems V-425E - Interface Specifications

42
4 Serial Port
Default Settings: Baud rate 9600, no parity, 8 data bits, 1 stop bit, XON/XOFF protocol and RTS/CTS.
4 USB
Connector Type : Type B
RS232 HOUSING (9-pin to 9-pin)
DB9 Socket
DB9 Plug
---
1 1
+5V,max 500mA
RXD
2 2
TXD
TXD
3 3
RXD
N/C
4 4
N/C
GND
5 5
GND
DSR
6 6
RTS
RTS
7 7
CTS
CTS
8 8
RTS
N/C
9 9
N/C
PC
Printer
Pin NO.
1
2
3
4
Function
VBUS
D-
D+
GND
APPENDIX Interface
