5 Accessories
35
CONNECTION CABLE
UPPER JACK
=
The printer MUST be turned OFF or the motherboard may be damaged!
=
There are 2 jacks: the lower jack is for the Label Dispenser, the upper jack is for the Cutter.
NOTICE
Secure the cutter using the screws provided.
SCREWS
Connect the Connection Cable on the Cutter to the upper jack on the front of the printer as shown below.
