Tharo Systems V-425E - Printer Access

To Next Page

To Previous Page

1 Barcode Printer

Open Cover

4 Open Print Mechanism

PRINTHEAD PRESSURE ADJUSTMENT SCREW ( LEFT )

PRINTHEAD PRESSURE ADJUSTMENT SCREW ( RIGHT )

LABEL SUPPLY MODULE

- LABEL SUPPLY HUB

- LABEL GUIDE PLATES ( 2 )

RIBBON MODULE

- RIBBON FEED MECHANISM

- RIBBON HUB

- EMPTY RIBBON CORE

LABEL GUIDE ( RIGHT )

RELEASE CATCH ( RIGHT )

RIBBON SUPPLY HUB

RELEASE CATCH ( LEFT )

LABEL GUIDE ( LEFT )

PRINT MECHANISM

PLATEN ROLLER

LABEL SENSOR

PRINT LINE ADJUSTMENT SCREW
