The Singing Machine SMVG-608 - Rear Panel Connections

CONTROL LOCATIONS
E6
ENGLISH
REAR VIEW
SIDE VIEW
23. AUX OUT Jack (L)
24. VIDEO OUT Jack
25. AUX OUT Jack (R)
26. OUT Jack
27. DC Jack
28. AC Power Cord
29. MIC 1 Jack
30. MIC 2 Jack
31. VIDEO
32.
CAMERA CONTRAST Button
HEADPHONE Jack
23 24
25 26 27 28
29
30 3231
