CONTROL LOCATIONS
6
REAR VIEW
REAR VIEW
46. Rod Antenna 50. VIDEO OUT Jack 54. BRIGHTNESS Control
47. Mic Holder 51. AC POWER Cord 55. VERTICAL HOLD Control
48. AUX OUTPUT Jack (R) 52. Mic Holder
49. AUX OUTPUT Jack (L) 53. CONTRAST Control
FRONT VIEW
1. Monitor 16. AUX INPUT Jack (L) 31. PLAY/PAUSE Button
2. Model Number 17. AUX INPUT Jack (R) 32. BAND Selector
3. CD Door Open Lid 18. BALANCE Control 33. FM (ST.) Indicator
4. CAMERA Lens 19. MASTER VOLUME Control 34. Dial Pointer
5. CDG LED 20. VIDEO OUT Selector 35. PLAY/PAUSE LED
6. LED Display 21. Cassette Door 36. TUNING Knob
7. REPEAT LED 22. RECORD Button 37. SKIP Button
8. REPEAT Button 23. PLAY Button 38. HEADHONE Jack
9. STOP Button 24. REWIND Button 39. AUTO VOICE CONTROL
10. FUNCTION Selector 25. FAST FORWARD Button 40. MIC 1 Jack
11. SKIP Button 26. STOP/EJECT Button 41. MIC 2 Jack
12. ON/OFF LED 27. PAUSE Button 42. ECHO Control
13. ON/OFF Button 28. Loudspeaker 43. MIC VOLUME Control
14. VIDEO IN Jack 29. PROGRAM LED 44. MONITOR Selector
15. PITCH Control 30. PROGRAM Button 45. Loudspeaker
46
47
48
49
50
51
52
53
54
55
