21
Note: The LINK function is NOT a COPY function.
If you want to edit the limiter of the output channels 1/2/4,
you can enter the editing mode of output channel 1 by pressing
the related edit button and turning on the blue LED below the
output channel 1 LED meters. This assigns the “role” of master
and displays this channels parameters on the LCD:
Then press the edit button of output channels 2/4, turning on
their related blue LEDs. Now all parameters edited on output
channel 1, will also be applied to channels 2 and 4.
If you want to remove one of the linked channels from the link,
press the related edit button.
Exiting the editing of the master channel during a link session
will automatically terminate that session. The link will also
be automatically terminated if, during the editing of output
channels you jump across to begin editing an input channel or
vice versa.
Factory reset
In the event of the password being lost or any other reason
the user may require the unit to be reset to the original factory
settings, a “Factory Reset” that will clear all settings of the
DSP24 and return the device to the original factory setting, is
available to the user.
Note: Continuing with this process will mean the DSP24 will
re-initialize to the original factory settings and any previously
stored information and changed parameters will be permanently
lost.
• Use the following procedure to perform the factory reset:
1. While the DSP24 is switched OFF, simultaneously press the
ENTER+ESC+UTILITY buttons on the front panel.
2. Maintain pressure on all three buttons as you turn the
power switch to ON and the following LCD screen appears
on the DSP24:
3. Release the buttons and wait for the DSP24 to re-initialize.
Once completed, the DSP24 will resume regular operation as
though it was a new unit from the factory and no previously
changed parameters will be available for use any more.
