5
The “UTILITY MENU” [access by pushing the “UTILITY” button]
NAV/PM1 Encoder
[to navigate within the menus]
PM2 or PM3 Encoder
[to choose option, then ENTER to load it; (*)
indicates the selected option]
1 UTILITY MENU:......
<< System Utilities >>
1.1
SYSTEM UTILITY:
<<Input routing>>
Input routing
Source: Analog *
Source: Digital
1.2
SYSTEM UTILITY:
<<Power-on procedure>>
Power-on procedure
Fade-In: On *
Fade-In: Off
1.3
SYSTEM UTILITY:
<<Delay units>>
Delay units
Unit: Time (ms) *
Unit: Distance (m)
1.4
SYSTEM UTILITY:
<<Ramps on changes>>
Ramps on changes
Ramps: Off *
Ramps: On
(more about this later)
1.5
SYSTEM UTILITY:
<<Software version>>
Software version
Version: V1.00 *
(not editable)
2 UTILITY MENU:......
<< Program Utilities >>
2.1
PROGRAM UTILITY:
<< Recall a program >>
Recall a program
01: Preset 01
: :
16: Preset 16
2.2
PROGRAM UTILITY:
<< Save a program >>
Save a program
01: Preset 01
: :
16: Preset 16
2.3
PROGRAM UTILITY:
<< Delete a program >>
Delete a program
01: Preset 01
: :
16: Preset 16
3 UTILITY MENU:......
<< Interface utilities >>
NAV/PM1 Encoder
[to navigate within the menus]
PM2 or PM3 Encoder
[to choose option, then ENTER to load it; (*)
indicates the selected option]
3.1
INTERFACE UTILITY:
Interface Setup
Interface Setup
Source: USB
Source: RS485
4 UTILITY MENU:......
<< Security Utilities >>
4.1
SECURITY UTILITY:
User Password
User Password
[ ]
4.2
SECURITY UTILITY:
Enable Password
Enable Password
Password: Enable
Password: Disable *
(For the details about
the Password setting/
enable and unit lock,
refer to the section
“Utility menus use” )
MENU ‘Input A/B’, input channel editing
[access by pushing A/B buttons]
NAV/PM1 Encoder
[to navigate within the menus]
NAV/PM1 Enc PM2 Enc. PM3 Enc.
[to choose values for the parameters, no need to conrm the chosen
values, which are automatically loaded during the encoders use]
1 Input A/B
Gain
=
Gain
+0.0 dB
–
> Gain = +0.0 dB PAR1 N/A -12dB
:
+6dB
Same as PAR2
2 Input A/B
Delay
=
Delay
0.000ms (or m)
–
> Delay = 0.000ms PAR1 N/A 000.0000ms
[1 ms steps]
848.0000ms
000.0000ms
[20.8 µs steps]
000.9984ms
3 Input A/B
1.00 kHz
PEQ/SHV
BW/SHV_
slope=1.00/
up to -12dB
+0.0dB
(when the lter’s gain = 0.0dB ONLY, through the PM2 it is
possible to choose and select between a bell or a shelving
lter)
