The t.racks ACHAT DSP24 User Manual

ACHAT DSP24 • OWNER’S MANUAL
6
NAV/PM1 Encoder
[to navigate within the menus]
NAV/PM1 Enc PM2 Enc. PM3 Enc.
[to choose values for the parameters, no need to conrm the chosen
values, which are automatically loaded during the encoders use]
If through the PM2, being the
lter’s gain = 0.0dB, with a bell
lter selected, just dening its
Bandwidth BW to be greater then
0, then the bell lters can be set by
the following parameters:
3.1 Input A/B
–
>1.00 kHz
EQ-X (up to 5 lters
available)
BW=1.00 +0.0dB
[Freq.] 20Hz
:
20kHz
[BW] 0.05
:
3.00
[Amp.] -15.0dB
:
+15.0dB
If through the PM2, being the
lter’s gain = 0.0dB, has been
selected a low shelving lter, just
dening its Slope (1
st
or 2
nd
order
available, -6dB or -12dB), then the
low shelving lter can be set by the
following parameters:
3.2 Input A/B
–
>1.00 kHz
EQ-X (up to 5 lters
available)
(-6/-12) LoSh +0.0dB
[Freq.] 20Hz
:
20kHz
PM2 N/A [Amp.] -15.0dB
:
+15.0dB
If through the PM2, being the
lter’s gain = 0.0dB, with a high
shelving lter selected, just
dening its Slope (1
st
or 2
nd
order
available, -6dB or -12dB), then the
high shelving lter can be set by
the following parameters:
3.3 Input A/B
–
>1.00 kHz
EQ-X (up to 5 lters
available)
(-6/-12) HiSh +0.0dB [Freq.] 20Hz
:
20kHz
PM2 N/A [Amp.] -15.0dB
:
+15.0dB
MENU ‘1/2/3/4’, output channel editing
[access by pushing 1/2/3/4 buttons]
NAV/PM1 Encoder
[to navigate within the menus]
NAV/PM1 Enc PM2 Enc. PM3 Enc.
[to choose values for the parameters, no need to conrm the chosen
values, which are automatically loaded during the encoders use]
1 Out-[X]
20.0 Hz
[Name]
No cut-off
HPF
–
> 20.0 Hz No cut-off PAR1 N/A [Freq.] 20Hz
:
20kHz
[Type/Slope] No Cut-Off
:
Bessel 24dB/Oct
2 Out-[X]
20.0 Hz
[Name]
No cut-off
LPF
–
> 20.0 Hz No cut-off PAR1 N/A [Freq.] 20Hz
:
20kHz
[Type/Slope] No Cut-Off
:
Bessel 24dB/Oct
3 Out-[X]
1.00 kHz
[Name]
BW/SHV
slope=1.00/
up to -12dB
+0.0dB
PEQ/
SHV
- 1/7
(when the lter’s gain = 0.0dB ONLY, through the PM2 it is
possible to chose and select between a bell or a shelving lter)
If through the PM2, being the
lter’s gain = 0.0dB, has been se-
lected a Bell lter, just dening its
Bandwidth BW to be greater then
0, then the Bell lters can be set by
the following parameters
3.1 Out-[X]
–
>1.00 kHz
[Name]
BW=1.00
+0.0dB
EQ-X
(up to
7 lters
available)
[Freq.] 20Hz
:
20kHz
[BW] 0.05
:
3.00
[Amp.] -15.0dB
:
+15.0dB
If through the PM2, being the
lter’s gain = 0.0dB, has been
selected a low shelving lter, just
dening its Slope (1
st
or 2
nd
order
available, -6dB or -12dB), then the
low shelving lter can be set by the
following parameters
