Rear Panel
The Thecus M3800’s rear panel features ports and connectors.
Back Panel
Item Description
eSATA Port • eSATA port for high-speed storage expansion
USB Port • USB 2.0 port for compatible USB devices, such as digital
cameras, USB disks, and USB printers
WAN Port • WAN port for connecting to an Ethernet network through a
switch or router
LAN Port • LAN port that can be used for connection sharing
PCI Slot • Reserved for future Thecus proprietary expansion
System Fan • System fan that exhausts heat from the unit
Power Connector • Connect the included power cords to these connectors
Reset Button
• Resets the M3800
• immediately press and hold the Reset button on the back for 5
seconds. This will reset your network setting, password, and
turn off Jumbo Frame Support.
11
