eSATA Information
Item Description
Model Displays the eSATA hard disk model name.
Capacity Shows the eSATA hard disk capacity in megabytes (MB).
Used Percentage Shows the capacity remaining on the eSATA hard disk in
percentage (%) and megabytes (MB).
Firmware Shows the eSATA hard disk firmware version.
Format Press Format to format your eSATA hard disk.
Eject Press Eject to unmount the eSATA hard disk.
Formatting will destroy all data on your eSATA hard disk. This data is not
recoverable.
WARNING
USB Disk Information
From the Storage menu, choose the USB
item and the USB Information screen
appears. From here, you can see various
items about USB disks connected to the
M3800.
USB Information
Item Description
Disk No. Number assigned to each USB disk.
Capacity (MB) Shows the capacities of each USB disk in megabytes (MB).
Model Displays the model names of each USB disk.
Firmware Shows the firmware version of each USB disk.
Status Shows the status of each USB disk. An Eject button appears
beside each USB disk. Press this button before removing the
USB disk.
Refresh Press Refresh to rescan the status of the USB disks.
RAID Information
From the Storage menu, choose the RAID
item and the RAID Information screen
appears.
This screen lists the RAID volume currently
residing on the M3800. From this screen,
you can get information about the status of
your RAID volume, as well as the status,
used percentage, and stripe size.
To configure your RAID settings, press the
Config button to go to the RAID
Configuration screen.
26
