N8200XXX/N8800 series:
The Thecus N8200XXX/N8800 series front panel has the device’s controls,
indicators, and hard disk trays:
Front Panel
Item Description
1.Power Button Power on/off N8200XXX/N8800
2.Power LED Solid green: System is power on.
3.Reboot Button Press to system reboot
4.System fan alarm
LED
Solid red: system fan failure notification
5. Mute button Mute the system fan alarm.
6.USB Port
USB 2.0 port for compatible USB devices, such as USB disks, USB
printers
7.Up Button ▲ Push to scroll up when using the LCD display
8.Down Button ▼ Push to enter USB copy operation screen
9.Enter Button Push to enter LCD operate password for basic system setting
10.Escape Button
ESC
Push to leave the current LCD menu
