THERM PRO TP-60S - Temperature and Humidity Trend Indicators; Outdoor Remote Sensor Features

1. indicates the temperature & humidity is in an
increasing trend.
Temperature & Humidity Trend
2. indicates the temperature & humidity is in an no
change trend.
3. indicates the temperature & humidity is in a
decreasing trend.
Outdoor Remote Sensor (Transmitter) Features
3
1
2
4
5
7
6
Buttons
CHANNEL Selector (1,2,3): Slide to set Channel 1,2 or 3.
1. Battery Compartment: Holds 2 X AAA batteries to power
the unit.
2. Rain-proof and design.wall-mounted
3. Outdoor Temperature range: .-4°F~158°F(-20°C~70°C)
4. Humidity range: 10% ~ 99%.
1. TX LED
2. Wall hanging hole
RESET
4. TX
3.
5. Channel 1.2.3
6. 2*AAA battery
Sensor detection port7.
-10-
-11-
ENEN
RESET: Press once to reset the remote sensor.
TX: Press to send temperature/humidity data to the receiver
manually.
