THERMACUT EX-TRAFIRE 75SD - Rear Panel Connections

EX-TRAFIRE
®
75SD
Operator Manual, Revision T-5 4-35
Rear control panel detail
Rear view
Rear control panel
1� Power supply switch
2� Mains power lead
3� CNC interface connector
4� Gas supply input fitting G1/4” Female
4
3
1
2
EX-TRAFIRE
®
75SD - 3 x 220 V EX-TRAFIRE
®
75SD - 3 x 400 V
