SERVICE 5-6 Manual 0-2805
B. Fuse Replacement
1. Remove the unit cover per paragraph "A" above.
2. Locate the internal fuse on the left side of the cen-
ter chassis.
3. Replace the fuse. Refer to Section 6.04 for proper
fuse specification.
4. Reinstall the cover by reversing the steps in para-
graph "A" above.
A-02957
Fuse Location
Internal Fuse Location
This completes the parts replacement procedures.
