Thermal Solutions Boiler Control TSBC User Manual

TSBC Instruction Manual Page 39 of 48
Trouble Shooting
Diagnostic Menu (Continued)
Display Description
DISCRETE OUTPUTS
These screens provide a convenient way to trouble shoot wiring during the
installation phase. Each screen provides the status of a controller output.
These displays show the status of the corresponding Discrete Output.
ANALOG INPUTS
These screens provide a convenient way to trouble shoot wiring during the
installation phase. Each screen provides the status of a controller analog
input.
These displays show the status of the corresponding Analog Input.
ANALOG OUTPUTS
These screens provide a convenient way to trouble shoot wiring during the
installation phase. Each screen provides the status of a controller analog
Output.
These displays show the status of the corresponding Analog Output.
Boiler Demand
0%
Mix Valve Demand
0%
