Macho Direct
5
Exploded View
Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
LGA2011 Type B Screw Pillars
Intel 2011/2011-3
Heatsink Body
Fan Clip
TY-140 Black
Anti-Vibration Pads
Mounting Plate
M3L6 Screw
Motherboard
M3L7 Screw
