Thermia Atlas Technical Description

3 Atlas 12 400V & 230V
3.1 Technical data, Atlas 12
Atlas 12 400V and 230V Unit 3-12 kW
Refrigerant Type R410A
Amount
1
kg 1,40
GWP 2088
CO
2
equivalent
tons 2923
Design pressure Bar (g) 45
Compressor Type Scroll
Oil POE
Electrical data, 400V, 3-N Mains power supply Volt 400~3N
Max working power, compressor kW 4,3
Rated power, circulation pumps kW 0,2
Immersion heater, 3 steps kW 0/3/6/9
Fuses, combined
2
A (10)/16/20/25
Electrical data, 230V, 3-P Mains power supply Volt 230~3
Max working power, compressor kW 4,3
Rated power, circulation pumps kW 0,2
Immersion heater, 3 steps kW 0/3/5/8
Fuses, combined
2
A (25)/32/32/40
Fuse separate supply (compressor only) A 25
Fuse separate supply, Immersion heater only A 16/25/40
Electrical data, 230V, 1-N Mains power supply Volt 230~1N
Max working power, compressor kW 4,3
Rated power, circulation pumps kW 0,2
Immersion heater, 3 steps kW 0/3/5/8
Fuses, combined
2
A (25)/40/50/63
Fuse separate supply (compressor only) A 25
Fuse separate supply, Immersion heater only A 16/25/40
Performance
SCOP, floor heating (35°C)
3
5,86
SCOP, radiator heating (55°C)
3
4,39
COP
4
4,75
Energy class-system
5
Floor heating (35°C) A+++
Radiator heating (55°C) A+++
Energy class-product
6
Floor heating (35°C) A+++
Radiator heating (55°C) A+++
Hot water (Economy)
7
A+
Hot water (Normal/Comfort)
8
A
Min/Max temperature Brine °C 20/-10
Heating °C 65/20
Anti freeze type 9 Ethanol + water solution -17°C ± 2
Pressure limits refrigerant
circuit
Low pressure bar(g) 2,3
Operating pressure bar(g) 41,5
High pressure bar(g) 45,0
Technical description Atlas & Calibra
Thermia AB BWCA01TD0202
11
