Thermia Atlas Technical Description

4 Atlas 18 400V
4.1 Technical data, Atlas 18
Atlas 18 400V and 230V Unit 4-18 kW
Refrigerant Type R410A
Amount
1
kg 1,95
CO
2
equivalent
tons 4,072
Design pressure Bar (g) 45
Compressor Type Scroll
Oil POE
Electrical data, 400V, 3-N Mains power supply Volt 400~3N
Max working power, compressor kW 6,7
Rated power, circulation pumps kW 0,3
Immersion heater, 3 steps kW (0)/3/6/9
Fuses, combined
2
A (13)/20/25/32
Performance
SCOP, floor heating (35°C)
3
6,15
SCOP, radiator heating (55°C)
3
4,55
COP
4
4,98
Energy class-system
5
Floor heating (35°C) A+++
Radiator heating (55°C) A+++
Energy class-product
6
Floor heating (35°C) A+++
Radiator heating (55°C) A+++
Hot water (Economy)
7
A+
Hot water (Normal/Comfort)
8
A
Min/Max temperature Brine °C 20/-10
Heating °C 65/20
Anti freeze type 9 Ethanol + water solution -17°C ± 2
Pressure limits refrigerant
circuit
Low pressure bar(g) 2,3
Operating pressure bar(g) 41,5
High pressure bar(g) 45,0
Sound power level Atlas dB(A)
32-45
10
(36)
11
Atlas Duo dB(A)
33-46
10
(37)
11
Hot water performance
Volume 40°C hot water
12
I 344
COP, hot water
7
3,05
Hot water including HGW
13
I 545
Hot water tank, size Atlas I 184
Atlas Duo I Optional
Water mains bar(g) 9
Weight Atlas, empty kg 187
Atlas, filled kg 377
Atlas Duo kg 147
Dimensions (WxDxH) Atlas mm 598x703x1863 +/-10
Atlas Duo mm 598x703x1450 +/-10
Technical description Atlas & Calibra
Thermia AB BWCA01TD0202
17
