Engine Maintenance 9-39
SLX, SLXe, SLXi Belt Replacement
SLX, SLXe, SLXi have both manual and automatic belt adjustment. Additionally it has special procedures to facilitate easy belt
changes.
Belt Arrangement – SLX, SLXe, SLXi
1. Blower Belt
2. Alternator Pulley
3. 37 Amp Alternator
4. Belt Tensioner
5. Grooved Idler
6. Smooth Idler
7. Slider Block
8. Spindle Bracket
9. Shaft Assembly
10. Blower - Lower
11. Blower - Upper
12. Condenser Spinning
13. Motor Pulley
14. Motor 15HP
15. SLX Clutch Tensioner
16. Idler Pulley
17. Engine to Motor Belt
18. Belt Guard
19. Clutch
20. Motor Pulley
