34
Securing the Oil Drain Hose
Oil Drain Hose
1. Secure the oil drain hose directly under the unit to the cargo box with
the two supplied retaining clips and self tapping screws as shown.
2. Ensure there is no contact and adequate clearance between the oil drain
hose and the hose management caps. The cutout in the hose
management cap should be as large as possible with no sharp edges.
3. Lower retaining clip should be positioned in an location easily
accessible for servicing the unit. Your actual location will depend on
the distance between the bottom of unit to top of cab, etc.
