Table 2: Burner Specifications and High and Low Fire Heating Performance
* Based on #2 fuel (domestic heating) oil having higher heating value of 140,000
BTU per gallon.
** Based on an assumed steady state, thermal efficiency of 80%.
For more specific burner information, consult the Model AFG Oil Burner
Instruction Manual or contact Thermo Products, LLC. P.O. Box 217, North
Judson, IN 46366. Phone no. 574-896-2133.
Heating
Mode
Oil Pump
Pressure
(PSIG)
Oil Flowrate
@ Nozzle
(GPH)
Heat Input
Rate*
(BTUH)
Heat Output
Rate**
(BTUH)
Burner Model
Number
Air Tube
Combination
Nozzle
Type
High Fire 130 0.75 105,000 85,000
Low Fire 120 0.6 85,000 67,000
AFG-TP1501 AF35 BOSS
Simplex, 80
deg., hollow
cone
