SECTION 5
FEATURES
CONTROL PANEL:
1 2 3 4 5
1. POWER SWITCH: This 2-position rocker switch controls power to entire
unit. The switch is lit when power is ON.
2. CONTROL STATUS LAMP: This lamp is lit when power is being supplied to
heater and not lit when power to the heater is OFF.
3. PROGRAMMABLE CONTROLLER: Maintains chamber temperature and
provides a display of either chamber or set point temperatures.
4. OVER-TEMPERATURE STATUS LAMP: This lamp is lit when either an
over-temperature condition exists or the over-temperature thermostat is
improperly set too low.
5. OVER-TEMPERATURE THERMOSTAT: This hydraulic thermostat is set by
the operator to back up the control thermostat and safeguard the incubator.
11
