24
Installation
Mounting (NEMA 1 enclosures)
NEMA 1 cased drives come with 0.88 inch (22 mm) conduit holes
at the bottom of the case. The units may be vertically wall mounted
or horizontally bench mounted using the three keyholes on the
back of the case.
1. For access to the keyholes and the terminal strip, remove the
two screws from the front of the case by turning them
counterclockwise. Grasp the front cover and lift it straight out.
2. Install the mounting screws in the three keyholes.
3. Install conduit hardware through the conduit holes at the bottom
of the case. Connect external wiring to the terminal block.
4. Reinstall the front cover. Avoid pinching any wires between the
front cover and the case.
5. Replace the two screws to the front cover. Turn the screws
clockwise to tighten.
6. Set the POWER switch to the OFF position before applying the
AC line voltage.
Cased drives
Warning
Do not install, rewire, or remove this control with input
power applied. Doing so may cause fire or serious injury.
Make sure you have read and understood the Safety
Warnings before attempting installation.
