20 56.001.599 - rev. 02 - 2019 Coolmobile 21-25
English
Specications
CE declaration of conformance
THERMOBILE INDUSTRIES B.V., Konijnenberg
80, NL-4825 BD BREDA, declares fully under own
responsibility that the products:
Portable Airconditioner Coolmobile 21 and Coolmobile 25
to which this statement refers to, are in conformance
with the following regulations:
Machinery regulations: 2006/42/EC
Low voltage directive: 2006/95/EC
EMC-regulation: 2014/30/EU
EMF-regulation: 2013/35/EU
The Netherlands, Breda,
25-06-2019
M. de Vlieger
Managing Director
Konijnenberg 80, 4825 BD Breda, The Netherlands
Company number: 3502
Tel. +31 (0) 76 587 34 50 Fax +31 (0) 76 587 27 89
E-mail: info@thermobile.com
Internet: www.thermobile.com
ITEM Coolmobile 21 Coolmobile 25
Cooling capacity BTU/h
kW
21,000
(6.15)
25,000
(7.33)
Power supply 230v. 50Hz. 1Ph.
Dimensions mm. 490 X 600 X 1,303
Weight kg. 86 90
Evaporator air ow m³/hr 660-780 840-960
Noise level (at 1m) dB 61 65
Power consumption kW. 2.22 2.6
Current consumption Amp 9.8 13
Refrigerant (R-410C) grm 890 1200
Air lter 08-07-2006 Aluminium mesh cartridge
Safety devices
- High Pressure Switch - Fan motor protection
- 3 min. delay timer. - Tank position indicator.
- Thermostat and relief valve tor compressor
- Auto ‘Full Tank’ shut o.
Power cable DEVICE Plug
Length 3 meters
Operating range 22°C to 45°C (Coolmobile : 22°C to 40°C)
Hight pressure kgf/cm² 26
Low pressure kgf/cm² 5
Max. duct length
(Either hot or cold, not both)
Cold duct (m) 9 12
Hot duct (m) Optional
Fuse in power box in machine body 250 Va.c. 5amp
