INSTALLATION
This appliance must be positioned free from draughts, which may affect the combustion,
and in a manner that will prevent the accumulation of unburnt gas. When in use ensure
that air vents are not inadvertently blocked or shut off. Ensure all combustible materials
such as curtains and shelves are well clear of the appliance.
If other appliance/s are located below the oven we recommend conducting a temperature
verification test to confirm any rise in temperature of the cabinet materials are within
allowable limits and meet requirements specified in EN30-1-1, EN1949, EN1645-1,
EN1646-1, EN1647, and EN721.
The performance of this appliance meets the requirements of the European Standard for
Domestic Cooking Appliances (EN30) which specifies a maximum allowable temperature
rise of the furniture into which the appliance is installed of 65
o
C above the ambient
temperature. It is important the installer verifies the furniture construction material and that
it is suitable for the application - i.e. plastic materials used in the construction may have a
softening point lower than the maximum allowable temperature rise specified in the
European Standard.
We recommend the installation follows the minimum dimensions shown in this manual as
any deviation could result in excessive temperature rise. If minimum dimensions must be
reduced, due to design constraints, a temperature rise test of all furniture fitted around the
unit MUST be performed. The design is deemed permissible providing the results of this
test comply with the allowable temperature rise specified above and with all standards in
force. In addition comply with all requirements detailed within the furniture manufacturer’s
material specification. Where minimum dimensions are reduced we recommend protecting
with non combustible material.
On completion of the installation a warning notice complying with EN721 Annex A should
be affixed adjacent to the appliance.
Gas Connection
Prior to connection ensure the local conditions for gas type and gas pressure match the
appliance specification. (Gas type and pressure for this appliance are printed on the data
badge located on the base of appliance)
The Ø8mm gas inlet is located to the rear of the appliance. Prior to connection remove the
plastic protection plug from the fitting. The appliance MUST be connected using metal pipe
manufactured from either copper, seam welded steel, seamless steel or stainless steel,
which complies with the requirements of EN1949. Rubber tubing MUST NOT be used.
• After installation the appliance MUST be tested for soundness
• The gas supply pressure to which this appliance is connected MUST
not rise or fall by more than 2.5mbar from nominal, when all appliances
connected to the supply are operated simultaneously.
