INSTALLATION
Electrical Connection
Cooling System: - A constant 12V supply is necessary at all times to ensure the cooling
system operates correctly.
Spark Ignition: - The spark ignition generator MUST only be connected to a suitable
12V DC supply. We recommend using sheathed spade connectors to
connect the generator to the power supply.
Ensure all electrical cables and wires are routed well clear of any heat source, including
this appliance. Excess cord must be routed away from the appliance and must not come
into contact with the oven or grill body. Any plugs must be accessible after installation to
aid servicing.
To ensure correct operation and prevent changes in air pressure affecting
performance we recommend the following installation requirements:-
• Built into self contained cabinet which is not connected to externally
vented chambers in adjacent furniture, other than correct size gas
dropouts.
• The installation must ensure free exchange of air between enclosure
and living environment.
• Holes for cables & pipes have minimum clearance where possible
• A gas dispersal hole MUST be fitted, this must not exceed Ø25mm
• Cupboards below appliance MUST not allow gas to enter the living
Construction materials: - All cooking appliances become hot during use. It is
important that the installer verifies the furniture construction material and
that it is suitable for the application - i.e. Plastic materials used in the
construction may have a softening point lower than the maximum allowable
temperature rise specified in the European Standard (EN 30-1).
If it is not possible to install the appliance as detailed within these
instructions please refer to Thetford Ltd for guidance.
