Tables

Table 1 : Status word ...........................................................................................................16

Table 2 : Measured value telegram ......................................................................................18

Table 3 : Sensor data telegram ............................................................................................18

Table 4 : MODBUS Frame ...................................................................................................19

Table 5: MODBUS Exceptions .............................................................................................19

Table 6 : MODBUS Input Register ........................................................................................23

Table 7 : List of commands ..................................................................................................25

Instructions for use

These instructions for use describe all application and adjustment options for the device.

These detailed instructions allow users to modify the factory settings to their needs via the

serial interface of the Weather Station Compact WSC10.

Scope of supply

1 Weather Station Compact WSC10.

1 Copy of the instructions for uses.

For assisting the parameter settings and/or special configurations there is our cost-free

Device Utility Tool art.-no. 9.1700.81.000 available for download on our homepage. Please

download the tool with following link.

Link: https://www.thiesclima.com/de/Download/

In the section "General", the program "Thies Device Utility".

1 Device version

Designation Order No.

Output

terminal

Data format Operating voltage

WEATHER STATION

Compact WSC10

4.9042.00.000 1 x RS485

Data in ASCII format

(command interpreter:

THIES)

24V DC

+10% / -30%

WEATHER STATION

Compact WSC10

4.9042.00.001 1 x RS485

Data in Binär format

(command interpreter:

MODBUS-RTU).)

24V DC

+10% / -30%
