THM Clavicula M3 - Tightening Torques; Permitted Application Areas

11
Clavicula M³
Specifications
Tightening torques
WARNING
Risk of accident caused by a malfunctioning crank system due to loose screw connections.
-Check the required tightening torque of all screw connections after the first 100 km - re-
tighten the connections if necessary. Repeat this check every 2500km!
Application area
WARNING
Risk of accident caused by a malfunctioning crank system due to overload.
-Only ever use your Clavicula component within its permitted area of application.
X1 Racing cycle and light cross-country terrain
X2 Touring, road
X3 medium/heavy terrain
X4 Free ride, heavy terrain
X5 Downhill, extreme terrain
N·m(lbf·in) max.
Bearing cups 40 (354) greased
Adjusting screw 6 (53) dry
Crank clamping bolt 8 (71)
with thread lockHollow screw for spider 6 (53)
Lockring spider 30 (266)
Chainwheel bolts, aluminium 6 (53)
greasedChainwheel bolts, steel 12 (106)
Pedal threads 20 (177)
Clavicula M³ Road X1–X2
Clavicula M³ MTB X1–X3
