THM Clavicula M3 - Spacers; Bb30; (D) Bbright Pressfit; Press-Fit (Shimano )

13
Clavicula M³
Assembly
Spacers
E-TYPE,
Chain-
guide, …
E-TYPE,
Chain-
guide, …
A
B
C
D
E
F
G
H
I
K
Bottom bracket
housing
Bottom bracket
Front derail-
leur type
Spacers
Fig.
Anticlockwise Clockwise
68.0mm (70.0mm)
Road BSA (ITA);
BB30 Road; PressFit
30 Road
Clip-on/
braze-on
0 0
(A)
MTB BSA
1× 2.5mm
2× 2.5mm
(B)
E-TYPE 1× 2.5mm + E-TYPE
(C)
BB30 MTB Clamp 1× 2.5mm
(D)
73.0 mm
BB30 MTB; PressFit
30 MTB
Clamp
0
0
(A)
MTB BSA
1× 2.5mm
(E)
E-TYPE 0 + E-TYPE
(F)
79.0 mm
BBright™ PressFit
Road
Clip-on/
braze-on
0 0
(G)
BBright™ Direct Fit
Road
–
84.0 mm
BBright™ PressFit
MTB
Clamp 00
(G)
86.5 mm
Press-fit
Road;Evo386 Road
Clip-on/
braze-on
0 0
(H)
89.5 mm Press-fit MTB sym. Clamp 1× 2.0mm 1× 2.0mm
(I)
92.0 mm Press-fit MTB asym. Clamp 1× 2.0mm 0
(K)
